Architectural drafter needed for existing & proposed bathroom drawings
Job description
Draughting Services Mount Albert, AucklandPublished on 14th February 2026
I’m looking for an experienced architectural drafter / architectural designer to convert drawings I’ve already prepared into a council-ready building consent set for a bathroom renovation.
The scope also includes skylights above the bathroom.
I do not have skylight or roof details drawn, so these will need to be documented as part of the consent drawings.
The design intent is clear, but I need help with:
-Producing a full NZ council-ready consent set
-Add correct dimensions, annotations, notes, and schedules
-Include roof / section details for the skylights as required
-Ensure compliance with the NZ Building Code and council requirements
This is not a design-from-scratch job, but it does require experience preparing consent documentation and filling in standard construction details where needed.
Ideal for someone who:
-Regularly prepares building consent drawings in NZ
-Has experience with bathroom renovations and skylights
-Understands council documentation standards
Happy to answer questions and share further info once shortlisted.
Verified work review
| Quality of work |
5.0
|
| Cost |
4.0
|
| Schedule |
5.0
|
| Communications |
5.0
|
"Great to work with—handled the drawings and council consent smoothly, with clear, consistent communication throughout."
Work carried out by the owner/operator
Review posted by Isaac on 5th May 2026
Tradesperson reply
"Thanks for the great feedback - appreciate it. It was a pleasure working with a design-oriented client, and I’m glad we could get everything through council smoothly. All the best with the build, and feel free to reach out if you need anything further."
5th May 2026
